DIMENSIONS
KIT CONTENTS
Your RX-399-IR kit is composed of :
- 1 white micro-camera with 4 IR LEDs (cable length = 2 m)
- 1 barrel/4 pin adapter of 54 cm
- 1 fixing adhesive
- 1 screw kit (nut, lock nut, washer)
/! Please note that the camera only has a length of 2 m and a 54 cm adapter. We advise you to equip yourself with an additional extension cable to connect it to a monitor (ref. RX-45/5, RX-45/15, RX-45/20).
FEATURES
- 170° viewing angle
- IP67 waterproof rating
- PAL/NTSC system
- Night vision 0 lumen min.
- 4 IR LEDs (distance 8 meters)
- Power supply DC 12~24V
- Consumption 60 mA
- Operating temperature -20°C / +70°C
CAMERA FUNCTIONS
Green loop = Mirror effect
To reverse the horizontal orientation of the camera (left/right), the green loop on the camera must be cut.
Blue loop = Image inversion
To reverse the vertical orientation of the camera (up/down), the blue loop on the camera must be cut.
White loop = Template lines
• White loop closed (uncut), the limits appear on the screen.
• White loop open (cut), the limits no longer appear on the screen.
2 POSSIBLE TYPES OF INSTALLATION
You can install your camera according to 2 types of vision; vision in reversing camera & vision in rear view :
